MECER Axpert Hybrid 5000VA 5000W Inverter Charger 4000W MPPT 220V 48V DC PF1 64V Battery Charger
2 YEAR CARRY IN WARRANTY + FREE SHIPPING IN SA
SKU SOL-I-AX-5P64
Features:
MECER Axpert_MKS 5000VA / 5000W Hybrid Pure Sine Wave Inverter Power factor 1, 64 VDC Charger, MPPT Solar charge Controller 4000W 80Amp, 220V AC Input, 48V DC Battery Input, 80Amp AC Battery Charger, Overload and short circuit protection, Configurable AC/Solar Input Priority, 13.5Kg, Up to 9 of these unit can be connected in parallel
- Pure sine wave inverter
- Output power factor 1 (only 0.8 for 3KP/5KP Models)
- Built-in battery equalization function to extend battery life cycle
- Built-in MPPT solar charge controller
- Selectable input voltage range for home appliances and personal computers
- Selectable charging current based on applications
- Configurable AC/Solar input priority via LCD setting
- Compatible to mains voltage or generator power
- Battery equalization for optimized battery performance and lifecycle
- Parallel operation with up to 9 units only available for Axpert MKS 3KP/4KVA/5KVA*
Specifications and features
- RATED POWER 5000VA/ 5000W
- Parallel Capability Yes, 9 units
- INPUT Voltage 230 VAC
- Selectable Voltage Range 170-280 VA
- Frequency Range 50 Hz/60 Hz (Auto sensing)
OUTPUT AC
- Voltage Regulation (Batt. Mode) 230VAC ± 5%
- Surge Power 10000VA
- Efficiency (Peak) 93%
- Transfer Time 10 ms - 20 ms
- Waveform Pure sine wave
BATTERY & AC CHARGER
- Battery Voltage 48 VDC
- Floating Charge Voltage 54 VDC Max: 58 VDC (Optional 64 VDC, please check with sales)
- Overcharge Protection 60 VDC (Optional 66 VDC, please check with sales)
SOLAR CHARGER & AC CHARGER
- Maximum PV Array Power 4000W
- MPPT Range @ Operating Voltage 60VDC ~115VDC
- Maximum PV Array Open Circuit Voltage 145VDC
- Maximum Solar Charge Current 80A
- Maximum AC Charge Current 60A
- Maximum Charge Current 140A
- Maximum Efficiency 98%
- Standby Power Consumption 2 W
PHYSICAL
- Dimension, D x W x H (mm) 100 x 272 x355
- Net Weight (kgs) 13.5
OPERATING ENVIRONMENT
- Humidity 5% to 95% Relative Humidity(Non-condensing)
- Operating Temperature 0°C to 55°C
- Storage Temperature -15°C to 60°C
