Omnipower Plus 5kW Hybrid / Pylon 9.6kWh Package Including Cabinet

  • Sale
  • Regular price R 107,990.00

Omnipower Plus 5kW Hybrid / Pylon 9.6kWh Package Including Cabinet


Domestic scale hybrid storage system.

The 5.0kW rated power of the Omnipower Plus, when matched with four economic Pylon modules of 2.4KW each, delivers up to 4.6kW of continuous discharge power. That's perfect for supplying some of the higher powered electrical loads in the evening.

The Omnipower Hybrid products have a separate AC back-up circuit output for essential loads, so they can offer protection for certain important appliances in the event of a power failure

The included 9U battery cabinet is perfect storage solution for housing up to 4 x PylonTech US2000B PLUS Lithium-Ion batteries

This part is a special offer made up of the following items:

4 x US2000B-PLUS  Pylon US2000B Plus 2.4kWh Li-Ion Battery (excl. brackets)
1 x OPH-1P-5KW-48  Omnipower Plus 5kW Hybrid PV inverter
1 x BATTRACK-9U  Battery Cabinet 12U ( 4 x Pylon )
1 x KETO-00  Fuse-switch-disconnector KETO size 00 body (battery isolator)
1 x CAB-PK-PYLON  Cable Pack for US2000B / Phantom-S Batteries
1 x BAT-HAZ-PACK  Battery Hazard Label Pack
2 x N5014907-160A  NH Fuse-link 160A for KETO-00
1 x BATCAB35-1M-RED  35mm2 Battery Cable (H01N2-D) 1m - Red
1 x BATCAB35-1M  35mm2 Battery Cable (H01N2-D) 1m - Black
4 x LUG35-8  35mm2 Cable Terminal Lug M8 - Single
